The Sweetwater Float Valve is a durable, automatic water level control valve designed for livestock water troughs, storage tanks, reservoirs, and other low-pressure water systems. Manufactured for reliable operation, it maintains a consistent water level by automatically opening when the water level drops and closing once the desired level is reached.

Available in both mild steel and stainless-steel construction, the Sweetwater Float Valve is built to withstand demanding agricultural environments. The mild steel model is electroplated and powder-coated to provide excellent protection against corrosion and lime scale build-up, while the stainless-steel option offers enhanced corrosion resistance for harsh or highly corrosive conditions.

Designed for high-flow, low-pressure applications, these float valves are ideal for:

• Livestock drinking troughs

• Water storage tanks

• Reservoirs

• Agricultural water systems

• Gravity-fed water installations

The robust mechanical design ensures dependable performance with minimal maintenance, helping to prevent water wastage while ensuring a continuous supply of fresh water for livestock and irrigation applications.

Technical specifications

Product type: Mechanical Float Valve

Available materials:

• Mild Steel (Electroplated & Powder Coated)

• Stainless Steel

Applications:

• Water troughs

• Water tanks

• Reservoirs

• Agricultural water systems

• Livestock watering systems

Available sizes:

20/25 mm

• Water Inlet: 20/25 mm

• Approximate Flow Rate: 42 L/min @ 1 Bar

• Maximum Operating Pressure: 3 Bar

32/40 mm

• Water Inlet: 32/40 mm

• Approximate Flow Rate: 120 L/min @ 1 Bar

• Maximum Operating Pressure: 2 Bar

Key features

• Automatically maintains water levels.

• High-flow performance for rapid tank refilling.

• Available in mild steel or corrosion-resistant stainless steel.

• Mild steel version is electroplated and powder-coated for extended service life.

• Resistant to lime scale build-up.

• Durable construction for demanding agricultural environments.

• Simple mechanical operation requiring no electricity.

• Suitable for continuous daily operation.

• Easy installation and maintenance.

• Compatible with 110 mm and 125 mm float balls (sold separately).

Benefits

• Prevents water overflow and unnecessary water loss.

• Ensures livestock always have access to fresh water.

• Reduces manual monitoring and filling of tanks.

• Built for long service life in farming and irrigation applications.

• Reliable operation in low-pressure, high-volume water systems.

This product is an excellent solution for farmers, irrigation contractors, and agricultural operations looking for a dependable automatic float valve that delivers consistent water level control with minimal maintenance.

Contact Irrigation Unlimited today to find your nearest dealer and learn more about the complete Sweetwater float valves.
